24*10/00M RJ45 ports, 802.3af/at+2/10/100/1000M RJ45 ports Max power per POE port:30W Port 17-24 10M@transmission distance 250 meters Supply power with the spare line pair Built-in power supply

 24*10/100M POE ports 802.3af/at+2*gigabit Combo TP/SFP ports POE max power per port:30W Built-in power supply Fiber module excluded Fan inside

 16*10/100M POE ports, 802.3af/at+2*10/100/1000M RJ45 ports Max power per POE port: 30W. Port 9-16 support 10M@long transmission distance 250 meters Supply power with the spare line pair Built-in Power supply

 16*10/100M POE ports 802.3af/at+2*gigabit combo TP/SFP ports POE max power per port:30W Built-in power supply Fiber module excluded Fan inside

 8*10/100M POE port, 802.3af/at+2*10/100M Rj45 port 2. Max power per POE port:30W, total power:120W Port 1-8 support 10M@long transmission distance 250 meters Supply power with the spare line pair Built-in power supply

 4*10*100M POE port, 802.3af/at+2*10/100M RJ45 port 2 Max power per POE port:30W, total power:65W. Port 1-4 support 10M@long transmission distance 250 meters Supply power with the spare line pair Built-in power supply

• 2 separate relays with an adjustable delay rate • Adjustable Light Sensor • Robust Material • Adjustable Alarm Volume • Waterproof Housing

KEY FEATURES • The latest cooled IR detector makes the images farther and clearer. • Dual-Spectrum with thermal and visible light, easily extension Laser rangefinder and Laser illumination. • 640*512 thermal resolution with 88-1100mm continuous zoom lens. • Support intrusion, cross line detection etc VCA function. • Integrated ±0.01° high-precision Pan tilt, 120°/s high rotation speed, support a variety of scanning modes and target tracking. • All-weather ingress design, IP67 ingress class, anti-wind, water proof, anti-corrosion, anti- salty. • Support ONVIF standard protocol and SDK

• VOx uncooled focal plane detector with 400×300 resolution • NETD ≤ 40mK • 75/100 mm motorized focus thermal lens optional, 40x optical zoom module • Support temperature monitoring and abnormity alarm • Support human/vehicle detection and fire point detection (ship detection optional) • Intelligent analysis: intrusion, single line crossing, double line crossing, loitering, wrong-way, enter area, leave area • Support 3 temperature measurement rule types (spot, line, area) • Temperature measurement range: -20°C ~ 150°C (-4°F ~ 302°F) • Power off self-locking, strong wind resistance • Anti-frozen, IP66

• Uncooled Microbolometer sensor with 400×300 resolution • NETD Sensitivity ≤40mK • 30~150 mm motorized focus thermal lens, 10~860mm visible lens optional • Built-in defog processing mechanism, optional HD defog lens • Support 3 temperature measurement rule types (spot, line, area) • 17 color control • Reliable temperature-anomaly alarm • Power off self-locking, strong wind resistance • Anti-frozen, IP66

 Default: Metal Up to 2880x1620@25fps S+265/H.265/H.264 illumination Color: [email protected] Smart IR, IR Range: 30m Support tripwire, perimeter & Human/Vehicle Classification Built-in Mic, SD Card Slot Operating Conditions -40°~65°, 0~95% RH POE, IP67

 4mm Fixed Lens Up to 1920x1080@30fps S+265/H.265/H.264 illumination Color: 0.002Lux@ (F1.6, ACG ON) Support People Counting AI deep Learning detection algorithm provides highly precise recognition rate>98% Self-adaptive to height from 2.5m to 4m, ease of installation Plugin Free Operating Conditions -35°~65°, 0~95% RH POE, IP66

AI Visualized Panorama Wide-Area scene Real-time search Multi-target trajectory Virtual electronic fence Intelligent PTZ camera Linkage 24*7 All time Adaptability to harsh environment Low power Consumption Lightweight and easy to deploy HD picture Quality

Product highlights    small light face portable the size is only 161 * 205.5.* 290.5 mm  Wireless transmission instant connection distance up to 50 m  mobile power supply 8 hours of outdoor Mobile Patrol

 Supports optical and thermal bi-spectrum image Vanadium Oxide Uncooled Focal Plane Arrays Thermal Resolution 384×288. Optical Resolution up to 3072×1728@30fp illumination Color: [email protected] Optical zoom: 44×, digital zoom 16× Smart IR, IR Range: 300m Bulit-in Speaker Built-in Automatic Wiper Built-in Electronic Compas Support GPS/BDS S+265/H.265/H.264/M-JPEG Intelligent monitoring/Face Capture mode Support Human/Vehicle Classification Support Laser Point Plugin Free IP66

 Support Auto-tracking Up to 2880×1620@30fps illumination Color: [email protected] Optical zoom: 30×, digital zoom 16× Smart IR, IR Range: 200m S+265/H.265/H.264/M-JPEG Intelligent monitoring/ Face Capture mode Support Human/Vehicle Classification Plugin Free IP66

Auto-Tracking Early Warning (AEW) Up to 3072×1728@20fps illumination Color: [email protected] Optical zoom: 44×, digital zoom 16× Built-in Speaker Support Human/Vehicle Classification Face Capture/intelligent monitoring mode Smart IR, IR Range: 200m S+265/H.265/H.264/M-JPEG IP66

1/1.8” CMOS Sensor Up to 4MP 2560x1440@30fps Optical zoom: 63×, digital zoom 16× Min. illumination Color: [email protected] Smart IR, IR Range: 300m Laser Distance: 500m Built-in Speaker Built-in Wiper Built-in Electronic Compass S+265/H.265/H.264 Monitoring/Intelligent Monitoring/ Face Capture mode Auto-tracking Early Warning (AEW) Support Laser Point Alarm 8 in and 2 out,Audio 1 in and 1 out Plugin Free IP66 DC36V±25% POE++(IEEE802. bt)

"1/2.8" Starlight sensor 1080P@30fps 150m IR 25x optical zoom, Speed 0.1°~200°/s Low Iux 0.001Lux TVS 6000V protection Audio I/O 1/1 Alarm I/O 1/1 MicroSD card(512GB) Onvif Profile S/T/G/M, IP66"

HD Input S+265/H.265/H.264 video formats Connectable to the third-party network cameras Support live view, storage, and playback of the connected camera at up to 12MP resolution   HD Output HDMI and VGA independent outputs HDMI Video output at up to 4K resolution

 HD Input: S+265/H.265/H.264 video formats Connectable to the third-party network cameras Up to 40 IP cameras can be connected Supports live view, storage, and playback of the connected camera at up to 12MP resolution   HD Output: HDMI and VGA simultaneous output HDMI Video output at up to 4K (3840 × 2160) resolution

HD Input ·S+265/H.265/H.264 video compression ·Connectable to third-party network cameras ·Up to 160 IP cameras can be connected ·Supports live view, storage and playback of connected camera at up to 12MP resolution HD Output ·HDMI and VGA independent outputs ·HDMI Video output at up to 4K (3840 × 2160) resolution HD Storage ·24 SATA interfaces connectable for recording and backup on the front panel, up to 10TB for each HDD ·S+265 compression effectively reduces the storage space and costs by up to 75% HD Transmission ·4×RJ45 self-adaptive 10/100/1000 Mbps network interfaces Functions ·Centralized management of IP cameras, including configuration, parameter import/export, real-time information display, two-way audio, upgrade, etc. ·Connectable to smart IP cameras from Tiandy, recording, playing back and backing up of VCA alarms can be realized ·VCA detection alarm is supported ·Smart search for the selected area in the video and smart playback to make the playback efficiency ·Web6

 Full Metal Housing Motorized Lens 2.7-13.5mm Up to 3840×2160@30fps ·S+265/H.265/H.264/M-JPEG illumination Color: [email protected] Smart IR, IR Range: 50m Support Video Analytics Support Human/Vehicle Classification Built-in Mic, audio I/O 1/1, alarm I/O 2/1 Plugin Free Operating Conditions -35℃~65℃, 0~95% RH POE, IP67, IK10

 Motorized Lens 2.8-12mm Up to 3840x2160@20fps S+265/H.265/H.264/M-JPEG illumination Color: [email protected] Smart IR, IR Range: 50m Support Video Analytics Support Human/Vehicle Classification Plugin Free Operating Conditions -35°~65°, 0~95% RH POE, IP66, IK10

 Metal Housing Up to 2880x1620@25fps S+265/H.265/H.264 illumination Color: [email protected] Smart IR, IR Range: 30m Audio I/O 1/1,Alarm I/O 1/1 Support tripwire, perimeter Human/Vehicle Classification Built-in Mic, SD Card slot Operating Conditions -40°~65°, 0~95% RH POE, IP67

 Full Metal Housing Motorized Lens 2.8-12mm Up to 2592x1944@20fps S+265/H.265/H.264 illumination Color: [email protected] 120dB WDR Smart IR, IR Range: 30m Support tripwire and perimeter Built-in Mic, SD Card Slot, Reset Button Operating Conditions -40℃~60℃, 0~95% RH POE, IP67, IK10

 Full Metal Housing Motorized Lens 2.7-13.5mm Up to 2592×1944@20fps S+265/H.265/H.264 illumination Color: [email protected] Smart IR, IR Range: 30m Support tripwire and perimeter Built-in Mic, SD Card Slot, Reset Button Audio I/O 1/1, Alarm I/O 1/1 Operating Conditions -35℃~60℃, 0~95% RH POE, IP66, IK10

 Full Metal Housing Motorized Lens 2.7-13.5mm Up to 3072×1728@30fps, 1920x1080@60fps S+265/H.265/H.264/M-JPEG illumination Color: [email protected] Smart IR, IR Range: 50m Built in Mic&Speaker Support Video Analytics Support Human/Vehicle Classification Support Early Warning Support Face Capture Mode Built-in Mic, audio I/O 1/1, alarm I/O 2/1 Plugin Free Operating Conditions -35℃~65℃, 0~95% RH POE, IP67, IK10

 Full Metal Housing Motorized Lens 2.7-13.5mm Up to 2592x1944@30fps, 1920x1080@60fps S+265/H.265/H.264/M-JPEG illumination Color: [email protected] Smart IR, IR Range: 50m Support Video Analytics Support Human/Vehicle Classification Support Face Capture Mode Built-in Mic, audio I/O 1/1, alarm I/O 2/1 Plugin Free Operating Conditions -35℃~65℃, 0~95% RH POE, IP67, IK10

 Full Metal Housing Motorized Lens 2.7-13.5mm Up to 3840x2160@20fps S+265/H.265/H.264/M-JPEG illumination Color: [email protected] Smart IR, IR Range: 80m Support Video Analytics Support Human/Vehicle Classification Support Face Capture Mode Audio I/O 1/1, alarm I/O 2/1 Plugin Free Operating Conditions -35℃~65℃, 0~95% RH POE, IP67

 1/1.8 inch CMOS sensor Focus: 10-47mm Up to 3840X2160@30fps illumination Color: [email protected] S+265/H.265/H.264/M-JPEG Face capture/intelligent monitoring mode 6 warm lights, up to 45m IP67

Default: Metal Up to 2880x1620@25fps S+265/H.265/H.264 Min. illumination Color: [email protected] Smart IR, IR Range: 50m Support tripwire，perimeter&Human/Vehicle Classification Built-in Mic, SD Card Slot, Reset Button Operating Conditions -35℃~60℃, 0~95% RH POE, IP67

Metal Housing Motorized Lens 2.7-13.5mm Up to 2880×1620@25fps S+265/H.265/H.264 Min. illumination Color: [email protected] Smart IR, IR Range: 80m Support tripwire and perimeter Support Human/Vehicle Classification Built-in Mic, SD Card Slot, Reset Button Audio I/O 1/1, Alarm I/O 1/1 Operating Conditions -35℃~60℃, 0~95% RH POE, IP67

Full Metal Housing Motorized Lens 2.7-13.5mm Up to 2592x1944@30fps, 1920x1080@60fps S+265/H.265/H.264/M-JPEG Min. illumination Color: [email protected] Smart IR, IR Range: 80m Support Video Analytics Support Human/Vehicle Classification Support Face Capture Mode Built-in Mic, Audio I/O 1/1, alarm I/O 2/1 Plugin Free Operating Conditions -35℃~65℃, 0~95% RH POE, IP67

Full Metal Housing Motorized Lens 2.7-13.5mm Up to 2592x1944@30fps, 1920x1080@60fps S+265/H.265/H.264/M-JPEG illumination Color: [email protected] Smart IR, IR Range: 80m Support Video Analytics Support Human/Vehicle Classification Support Face Capture Mode Built-in Mic, Audio I/O 1/1, alarm I/O 2/1 Plugin Free Operating Conditions -35℃~65℃, 0~95% RH POE, IP67

Full Metal Housing Motorized Lens 2.7-13.5mm Up to 3072x1728@30fps, 1920x1080@60fps S+265/H.265/H.264/M-JPEG Min. illumination Color: [email protected] Support Video Analytics Support Human/Vehicle Classification Support Face Capture Mode Support Early Warning Built-in Mic&Speaker, audio I/O 1/1, alarm I/O 2/1 Plugin Free Operating Conditions -35℃~65℃, 0~95% RH POE, IP67

1/2.8" CMOS,F1.6,IR 80m 002Lux Up to 1920x1080@30fps 512 GB SD card slot Built-in Mic Audio I/O 1/1 Alarm I/O 1/1 IP67 ONVIF Profile S/T/G/M

Full Metal Housing Motorized Lens 2.7-13.5mm Up to 1920x1080@30fps S+265/H.265/H.264/M-JPEG illumination Color: [email protected] Smart IR, IR Range: 80m Support Video Analytics Support Human/Vehicle Classification Support Face Capture Mode Built-in Mic, Audio I/O 1/1, alarm I/O 2/1 Plugin Free Operating Conditions -35℃~65℃, 0~95% RH POE, IP67

Metal+Plastic Housing Up to 1920×1080@30fps S+265/H.265/H.264 illumination Color: [email protected] Smart IR, IR Range: 50m Built-In Mic Support tripwire and perimeter Operating Conditions -30℃~60℃, 0~95% RH POE, IP67

Up to 4000×3072@20fps S+265/H.265/H.264/M-JPEG Support Ceiling, Wall, Table Mounting Support Hardware Decoding and Software Decoding Support 360° Panoramic View, 180° Panoramic View, 4PTZ, Fisheye+3PTZ Mode Support Human/Vehicle Classification Built-in Mic & Speaker Smart IR, IR Range: 20m Operating Conditions -35°~65°, 0~95% RHG POE, IP66, IK10
